Description
LED fog lamp using CREE’s high-brightness LED
This product realizes brightness and long life by
using the reliable CREE’s 10W x 2 LED.
Built-in daylight function
Uses a reliable CREE 9.5W x 2 LED.
Built-in U-shaped daylight supports daytime driving. Equipped with a
function to turn off the lights in conjunction with small nighttime depending on the wiring, and
a switching function that can be used only with fog lights .
It is a versatile universal design accessory and comes with a conversion coupler to H8 / H11 / HB3 / HB4.
For vehicles equipped with H16 Please process and install the attached coupler. Since it is designed exclusively for
E-mark acquisition models can be replaced with genuine products.
There is no need to make a stay.
There is also an optical axis adjustment mechanism, so you can rest assured.
With optical axis adjustment mechanism
Up and down adjustment is possible by turning the screw on the backside of the main body.
Since the bezel body is also screwed, it has a wide adjustment range.
■ Connection method
[LED drive unit side]
・ Red line + (for daylight lighting / fog lighting): To ACC power supply, etc.
・ Yellow line + (connection only when daylight off function is used): To small, etc. * 1
・ Red + / Black-Line: To fog lamp wiring * 2
[Fog lamp body side]
4-pole coupler: To the LED drive unit
* 1: No
connection is required to the + wire of the fog lamp when turning off the fog lamp, and to the + wire of the fog lamp when the daylight extinguishing function is not used.
* 2: It does not light only by connecting the fog lamp wiring.
Be sure to connect the red wire of the LED drive unit before use.
If you do not use the accessory coupler (if there is no applicable coupler), connect it before use.
■ Each lighting method
[Daylight only lit]
Red-yellow line red → ＋
Red-black line black → －
[Fog lamp only lit]
Red-yellow line red → ＋
Red-yellow line yellow → ＋
Red-black line red → ＋
Red-black line Black →-
[Both are lit]
Red-yellow line red → +
Red-black line red → +
Red-black line black →-
